Diagonal Wheelbase

1133 mm

Dimensions

1668 mm × 1518 mm × 727 mm with propellers, frame arms and GPS mount unfolded (including landing gear)
437 mm × 402 mm × 553 mm with propellers, frame arms and GPS mount folded (excluding landing gear)

Package Dimensions

525 mm × 480 mm × 640 mm

Weight (with six TB47S batteries)

9.5 kg

Weight (with six TB48S batteries)

10 kg

Max Takeoff Weight Recommended

15.5 kg

Hovering Accuracy (P-GPS)

Vertical: ±0.5 m, Horizontal: ±1.5 m

Max Angular Velocity

Pitch: 300°/s, Yaw: 150°/s

Max Pitch Angle

25°

Max Wind Resistance

8 m/s

Max Ascent Speed

5 m/s

Max Descent Speed

3 m/s

Max Service Ceiling Above Sea Level

·                2170R propellers: 2500 m；

·                2195 propellers: 4500 m

Max Speed

40 mph / 65 kph (no wind)

Hovering Time* (with six TB47S batteries)

No payload: 32 min, 6 kg payload: 16 min

Hovering Time* (with six TB48S batteries)

No payload: 38 min, 5.5 kg payload: 18 min

Supported DJI Gimbals

Ronin-MX; Zenmuse Z30, Zenmuse X5/X5R, Zenmuse X3, Zenmuse XT; Zenmuse Z15 Series HD Gimbal: Z15-A7, Z15-BMPCC, Z15-5D III, Z15-GH4

Flight Control System

A3 Pro

Propulsion System

·                Motor model: DJI 6010

·                Propeller model: DJI 2170R

Retractable Landing Gear

Standard

Operating Temperature

14° Fto 104° F (-10° C to 40° C)

Voltage Output

26.1 V

Rated Power

600 W

Single Battery Port Output Power

100 W

Capacity

5700 mAh

Voltage

22.8 V

Battery Type

LiPo 6S

Energy

129.96 Wh

Net Weight

680 g

Operating Temperature

14°F to 104° F (-10°C to 40° C)

Max Charging Power

180 W

Operating Frequency

920.6 MHz to 928 MHz (Japan); 5.725 GHz to 5.825 GHz; 2.400 GHz to 2.483 GHz

Max Transmission Distance

FCC Compliant: 3.1 mi (5 km), CE Compliant: 2.2 mi (3.5 km) (Unobstructed, free of interference)

Transmitter Power (EIRP)

10 dBm @ 900M, 13 dBm @ 5.8G, 20 dBm @ 2.4G

Video Output Port

HDMI, SDI, USB

Operating Temperature

14°F to 104° F (-10° to 40° C)

Battery

6000 mAh LiPo 2S

Capacity

4500 mAh

Voltage

22.2 V

Battery Type

LiPo 6S

Energy

99.9 Wh

Net Weight

595 g

Operating Temperature

14° F to 104° F (-10°C to 40° C)

Max Charging Power

180 W
